Digital 0.001K Oxygen Bomb Calorimeter

1.Adopts technology of single chip machine, touch screen, windows system

2.Test procedure is fully automatic.

3.This instrument adopts sealed oxygen bomb. The whole structure adopts stainless steel material.

4.The inner water container is made of stainless steel and the section likes as a pear.

More products, click here.

Contact Now E-Mail Telephone WhatsApp

Product Details

XRY-1A+ Oxygen Bomb Calorimeter Price For Sale

It is appropriate to decide calorific price of flamable substances such as petroleum merchandise except water (gasoline, jet fuels, diesel oil and gas oils, etc.), coal, coke and paraffin, etc.

Main technical features
1. This instrument adopts sealed oxygen bomb. The total shape adopts stainless metal material. The power is adequate to face up to the max stress (60~70 atmospheric pressure) when the stable burning. And it can withstand the better stress when liquid gas burning.
2. The internal water cylinder is composed of stainless-steel sheet. The move part is pyriform, and the capability is 3kg. The water cylinder is outfitted with electric powered stirrer inside. It ensures the temperature in the water cylinder uniform.
3. The exterior water jacket is double layer container. It stuffed with water when doing determination. It makes the water temperature in the cylinder uniform with the aid of water jacket stirrer and shape the consistent temperature surroundings assembly the necessities of test.

Main technical specifications
1. Capacity: 14400 J/K～15000 J/K
2. Resolution: 0.001 K
3. Accuracy: ± 60J/g
4. Repeatability: ≤0.2%
5. Pressure : 20 MPa
6. Temperature size range: 10 ℃～35 ℃
7. Ambient temperature: 20±5 ℃, the fluctuation is now not extra than 1 ℃ for the duration of one test
8. Data saved: 31 pieces
9. Relative humidity: ≤85%
10. Power supply: AC 220V±5%, 50 Hz
11. Dimension:600mm×460mm×430mmPacking List

No	Name	Unit	Quantity	Remark
1	Main unit of calorimeter (including oxygen bomb, water jacket, bucket, stirrer and controller of calorimeter)	Set	1
2	Pellet press machine	Set	1	Optional
3	Holder of bomb head	Set	1
4	Seat of oxygen bomb	Set	1
5	Temperature sensor	Piece	1
6	Thermometer (0～50 ℃)	Piece	1
7	Stopper for thermometer (silica gel stopper 2#)	Piece	1
8	Ignition wire (Φ0.1 nickel-chrome wire)	Meter	10
9	Crucible	Piece	2
10	Discharging valve	Piece	1
11	Oxygen decompression device	Piece	1
12	Oxygen tube	Pair	1
13	“O” seal ring (Φ20×2.4 mm)	Piece	5
14	“O” seal ring (Φ8×1.9 mm)	Piece	5
15	“O” seal ring (Φ6×1.9 mm)	Piece	5
16	Seal ring (large “O” ring)	Piece	2
17	Ignition connection wire	Piece	1
18	Siphon	Piece	1
19	Benzoic acid	Piece	10
20	Stopping ring for thermometer (1#)	Piece	4
21	Fuse 2 A (Φ5×20)	Piece	2
